Stiebel Eltron DHC 8-2 Point-of-Use
Tankless Water Heater
Let us help you evaluate if tankless is right for you or help you select the best model for your application. Call us now...
DHC 8-2 Advantages:
• save space
• save energy
• reduce water waste
• simple installation
• very economical
• legendary Stiebel quality
Stiebel Eltron DHC 8-2 Tankless Brochure
Adobe PDF Format
Stiebel Eltron DHC 8-2 Tankless Installation Guide
Adobe PDF Format
the Stiebel Eltron DHC Series
tankless water heaters are independently tested to comply with U.S. & Canadian safety standards
Stiebel Eltron Tankless Water Heaters are tested and certified by WQA against NSF/ANSI 372 for "lead free" compliance.
Stiebel Eltron is
Quality you can count on!
Manufactured in Germany
Be the first to write a review.
Stiebel Eltron DHC 8-2
Our Price: US$179.00
You save: $46.00
Found a Lower Price?
Request a Price Beat
Limited Quantity of Factory Refurbished units available.
Save an additional $60.00!
- more info -
- 7.2 kW's of Power
- Compact Size
- Flow Control Activated
The Stiebel Eltron DHC series tankless water heaters are well built, economical, and ultra-compact point-of-use tankless water heaters designed for basic point of use applications. Basic point of use applications include many bathroom sinks, kitchens, commercial washrooms, emergency eyewash stations, etc. The DHC series is designed for applications with a relatively constant flow rate. If the flow rate will potentially fluctuate in your application due to varying water demands, incoming water temperatures, or water pressures, we recommend that you consider a DHC-E Series tankless water heater with thermostatic control and flow-based power modulation technology.
The Stiebel Eltron DHC 8-2 can conveniently fit directly under a sink or in an adjacent cupboard or closet, which allows it to deliver hot water to the application almost instantly. By locating the heater right next to the faucet, you can also virtually eliminate the thermal heat loss which is commonly associated with long pipe runs. If the DHC 8-2 can supply all of the hot water needs for the room, you may also be able to eliminate the need to run a hot water line all the way from the main central water heater. This can result in significant savings in plumbing and material costs.
By producing hot water on demand only as it is being used, the DHC 8-2 is extremely energy efficient. A sophisticated water flow sensor recognizes when hot water is turned on and when it has been turned off, so the unit will activate and deactivate automatically so it only runs when you are actually using hot water. The standby thermal heat losses associated with traditional tank type water heaters are therefore eliminated. You can expect to see a significant reduction in cost over operating a conventional water heater.
|Maximum Flow Rate in Gallons Per Minute at 105F Output Temp.|
|Incoming Water Temp:||Flow Rate (GPM)|
the Brochure for temp rise data at 208v input.
An exclusive scald-guard thermostat keeps the water temperature within safe limits at all times. Additionally, the DHC water heaters are equipped with a safety high-limit with manual reset. The rugged all copper design ensures many years of reliable service.
The Stiebel Eltron DHC 8-2 is not recommended for whole house use. For more information on whole house models, see our Stiebel Eltron Tempra Series Whole House Tankless Water Heaters.
|Stiebel Eltron DHC 8-2 Tankless Water Heater Specifications|
|@240 volts||@208 volts|
|KW||7.2 KW||5.4 KW|
|Voltage:||208 to 240 volts / single phase / 50 - 60 Hz|
|Max. Amps:||30 AMPS||26 AMPS|
|Breakers Required:*||1 x 30 AMP breaker|
|Wiring:*||Minimum #10 AWG Copper|
|Dimensions:||14.25 x 7.9 x 4.1" (36 x 20 x 11 cm)|
|Weight:||5.3 lbs (2.4 KG)|
|Pipe Fittings:||1/2" NPT|
|Activation Flow Rate:||0.69 GPM / 2.6 LPM|
|Max. Water Pressure:||150 psi|
|Warranty:||Manufacturer's 3 Year Warranty|
|Safety:||ETL Listed (US / Canada)|
|Protection:||scald guard thermostat and thermal hi-limit cut-out switch|
* Breaker size and wire gauge must meet all applicable local, state, provincial, and national electrical codes for your area - these are only guidelines that will apply to most installations. Please consult your electrician for more details.
